We manufacture and supply wide range of Gear Hobbing Machines which has maximum 8 module, 900 MM maximum Dia of gear, automatic lubricating, 3 H.P Main Motor and 2 H.P Rapid Motor. Our personnel make use of advanced technology and quality components to manufacture these machines as per the set industry standards. These Gear Hobbing Machines are available with following specifications:
| Technical Specifications | |
|---|---|
| Maximum Dia of gear | 900 MM |
| Maximum Module Capacity | 8 Mod. |
| Maximum hob slide travels | 381 MM |
| Diameter of work table | 582 MM |
| Work table bore | 76.2 MM |
| Maximum Dia of hob | 140 MM |
| Maximum tapper of hob spindle | 80 MM |
| Hob spindle speed (Feed varies by changing gears) | 6 Speed |
| Machine Height | 7 ‘1/2″ |
| Machine Length | 8′ |
| achine Length | 4’1/2″ |
| Electric Equipments | |
|---|---|
| Main Motor | 3 H.P. |
| Rapid Motor | 2 H.P. |
| Coolant Pump | 0.5 H.P. |
| Standard Equipments | |
|---|---|
| Work arbour | 1 1/4″ |
| Hob arbour | 1 1/4″ |
| Speed Gear | 1 Set |
| Change Gear | 1 Set |
| Total Weight (Approx.) | 4000 Kg. |
